Current Collectors

Thumbnail 1 Thumbnail 2 Thumbnail 2

CCV-20 (Metal Body)


Current Collector assembly consists of a spring loaded sliding contact type shoe of sintered copper graphite. Heavy duty double arm current collector provides multi axis degree of flexible movement. Exposed parts of current collectors shall be grounded and of corrosion-resistant material. Current collector assembly shall be designed to operate through gaps, splices, switches and shall be self centering.


Current Capacity : Up to 20 Amp. (Metal body)


Get Free Quote



Thumbnail 1 Thumbnail 2

CCW-125


Current Collector assembly consists of a spring loaded sliding contact type shoe of sintered copper graphite. Heavy duty double arm current collector provides multi axis degree of flexible movement. Exposed parts of current collectors shall be grounded and of corrosion-resistant material. Current collector assembly shall be designed to operate through gaps, splices, switches and shall be self centering.


Current Capacity : Up to 125 Amp. (Aluminum body)


Get Free Quote



Thumbnail 1 Thumbnail 2 Thumbnail 2

CCV-125


Current Collector assembly consists of a spring loaded sliding contact type shoe of sintered copper graphite. Heavy duty double arm current collector provides multi axis degree of flexible movement. Exposed parts of current collectors shall be grounded and of corrosion-resistant material. Current collector assembly shall be designed to operate through gaps, splices, switches and shall be self centering.


Current Capacity : Up to 125 Amp. (Metal body)


Get Free Quote




Thumbnail 1 Thumbnail 2

CCW-250


Current Collector assembly consists of a spring loaded sliding contact type shoe of sintered copper graphite. Heavy duty double arm current collector provides multi axis degree of flexible movement. Exposed parts of current collectors shall be grounded and of corrosion-resistant material. Current collector assembly shall be designed to operate through gaps, splices, switches and shall be self centering.


Current Capacity : 250 Amp. (Aluminum body)


Get Free Quote




Thumbnail 1 Thumbnail 2 Thumbnail 2

CCV-250


Current Collector assembly consists of a spring loaded sliding contact type shoe of sintered copper graphite. Heavy duty double arm current collector provides multi axis degree of flexible movement. Exposed parts of current collectors shall be grounded and of corrosion-resistant material. Current collector assembly shall be designed to operate through gaps, splices, switches and shall be self centering.


Current Capacity : 250 Amp. (Aluminum body Heavy)


Get Free Quote




Thumbnail 1 Thumbnail 2 Thumbnail 2

GRAVITY TYPE CURRENT COLLECTOR


We manufacture various types of current collector like single hinged, double hinged ,dsl ,gravity type current collectors are used to tap power supply from down shop leads to the moving crane. These current collectors with cast iron shoes will slide on the top of the angle iron type DSL system.


we also manufacture all type of current collector as per drawing / sample.


MODEL: CCAT-250 & CCAT-400
250 Amp. - 400 Amp
Material: Cast iron ,copper ,epoxy, porcelain Insulator, copper fixable Cable,


Get Free Quote
